FMAB

Case 79-2

1)

4)

max. 201

max. 151

2)

max. 56

(10)

1-Phase Line Filters

www.schurter.com/PG84

6.5 ±0.3

85 ±0.3

3)

M6

(17)

1) Line

2) Load

3) Nut torque 3...4 Nm

4) I/O Connections torque 1.5...1.8

Diagrams

Standard version

1)

1) Line?2) Load

Attenuation Loss

2)

- - - - differential mode _____ common mode

Industrial version

12 A

20 A

30 A

50 A

Variants

Rated Cur-

rent [A]

Filter-Type

Leakage Cur-

rent [mA]

L [mH]

C1

(X2)

C2 (Y2)

[nF]

C3

(Y2)

C4

(X2)

R [M ? ]

Clamps

[mm 2 ]

Weight

[g]

Housing Order Number

12

Industrial Version

5.2

2 x 10

2.2

10

47

1

1

4

927 g

24-2

5500.2064

20

30

50

Industrial Version

Industrial Version

Industrial Version

5.2

5.6

5.6

2 x 3.5

2 x 1.5

2 x 1.5

2.2

2.2

2.2

10

15

15

47

47

47

1

1

1

1

1

1

4

6

10

930 g

970 g

970 g

24-2

24-6

79-2

5500.2065

5500.2066

5500.2067

█

█ Most Popular.

Availability for all products can be searched real-time: http://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER

Packaging unit

2 Pcs

2

Connectors

The specifications, descriptions and illustrations indicated in this document are based on

current information. All content is subject to modifications and amendments.
